Single wall flue system
EW ECO CONDENSING: is a rigid, single wall chimney system certified to EN 1856-1, with a working temperature of up to 120 °C and pressure class P1. It includes a condensing joint seal for airtight performance and is suitable for both vertical and horizontal configurations.
Enquire with us today
Product information
EW ECO CONDENSING is Jeremias UK’s factory-made single wall flue system, purpose-designed for high-efficiency condensing boilers and appliances. Manufactured in AISI 316L stainless steel, this system offers excellent corrosion resistance against acidic condensates and is ideal for chimney relining or internal flue runs where insulation is not required.
Its lightweight, modular design allows for fast installation and easy on-site adaptation, making it a practical and economical solution for commercial buildings, retrofit projects, and plant rooms with limited space.
| EW ECO CONDENSING | CONDENSING FLUE LINER | |
|---|---|---|
| MATERIAL | AISI 316L | |
| INSULATION | ||
| WORKING TEMPERATURE | Up to 120ºC | |
| FINISHING | Standard: bright annealed (BA) RAL colours (check prices) |
|
| THICKNESS | 0,4 – 0,5 – 0,6 (according to diameter) | |
| AVAILABLE DIAMETERS (mm) | Ø80 to Ø600 | |
| CONNECTION SYSTEMS | Male-female connection secured by locking band | |
| FIRE RESISTANCE | ||
| CE CERTIFICATE | 0036 CPR 9174 029 | |
| EC CLASSIFICATIONS (UNE-EN 1856-1) | T120 – P1 – W – V2 – L50040 – O(00) |
