Freestanding industrial stacks
At Jeremias UK, we design and manufacture freestanding industrial stacks, also known as windshields, at our Blackpool facility, the largest production site in the UK for this type of solution. These self-supporting structures are engineered to accommodate single or multiple flue liners, and are the go-to solution for data centres, energy centres, and mission-critical infrastructure where flue heights exceed 25 metres and structural independence is essential.
Enquire with us today
Product information
UK’s largest production capacity for freestanding steel chimney stacks – backed by global engineering expertise
At Jeremias UK, we design and manufacture freestanding industrial stacks, also known as windshields, at our Blackpool facility, the largest production site in the UK for this type of solution. These self-supporting structures are engineered to accommodate single or multiple flue liners, and are the go-to solution for data centres, energy centres, and mission-critical infrastructure where flue heights exceed 25 metres and structural independence is essential.
Whether for a single generator or a multi-line CHP installation, Jeremias windshields offer unmatched flexibility, safety, and performance—delivered through a turn-key service that includes design, structural calculation, fabrication, transport, and installation.
Complete Range of Systems
Jeremias offers three main freestanding stack systems, each tailored to specific project needs:
- FSA:
Double-wall insulated chimney with a load-bearing external shell and single internal liner. Ideal for high-rise installations with thermal and structural separation. - FSA-X:
Multi-liner version of the FSA, supporting two or more internal flue liners within a single external stack. Perfect for data centres and energy hubs with multiple generator sets or heat sources - FSB:
A compact solution where the internal liner also acts as the structural support, eliminating the need for an external shell. Ideal for urban or space-constrained sites
Technical Highlights
- Manufactured in Blackpool, UK – with full CE marking and UKCA readiness
- Global production capacity with additional facilities in Germany, Spain, and Denmark
- Custom heights up to 60 metres
- Diameters up to Ø3000 mm
- Materials: AISI 304 / AISI 316L / S235 / S355
- Insulation: 30–250 mm rock wool or mineral wool
- Rear ventilation for thermal stability
- Access platforms, ladders, lightning protection, and emission monitoring ports available
- RAL painted or stainless steel finishes (matte, polished, brushed)
- Static calculations per EN 13084, EN 1993, and local wind/seismic loads
- Optional vibration dampers and Scruton spirals for wind-induced oscillation control
Ideal for:
- Energy-from-waste plants and industrial boiler houses
- Data centres (Tier III and IV) with high exhaust dispersion requirements
- Hospitals, airports, and critical infrastructure
- Sites requiring flue dispersion above 30 m
- Projects with complex logistics or restricted access
Global Engineering Know-How
The Jeremias Group brings over 40 years of experience in industrial chimney design and manufacturing, with 10 production plants and presence in over 60 countries. Our Industrial Division provides:
- Full engineering support: CFD, FEA, structural reports, and 3D/BIM design
- Certified manufacturing: EN 13084-7, EN 1090-2 EXC2/EXC3, ISO 13920
- In-house R&D and testing for acoustic, thermal, and structural performance
- References worldwide in sectors such as energy, data, food, pharma, and heavy industry
Why Choose Jeremias UK?
- Largest UK production capacity for freestanding steel stacks
- Turn-key delivery: design, structural engineering, fabrication, and installation
- Single and multi-liner configurations for flexible system design
- Proven performance in data centres, hospitals, airports, and industrial plants
- Backed by the Jeremias Group, the global leader in flue and chimney systems
